19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons

19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons
19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons 19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons

Large Image :  19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO9001
Model Number: S1908
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: To be negotiable
Packaging Details: customized
Delivery Time: 5-7 work days
Payment Terms: L/C, T/T
Supply Ability: 1000pcs per day

19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons

Description
Diameter: 19mm Advantage: Most Favorable Prices,Hight Effiency,High Strength
Feature: Top Impact-resistance,Hardness And High Heat Resistance Carbide Packaging: Plastic Pail Or Customized
Material: Carbide Cutter Model: 1008
High Light:

19mm Polycrystalline Diamond Compacts

,

anti impact carbide buttons Hainaisen

,

anti impact carbide button Hainaisen

PDC Cutter Tungsten Carbide Cutters For Drilling Tools Pdc Diamond



PDC tools are mainly used for oil drilling equipment and wearing parts of oil drill bits, coal drill bits and machining tools. They are made of high quality synthetic diamond powder and tungsten carbide powder. PDC tools combine the high hardness and wear resistance of diamond and tungsten carbide and can be used in a variety of drilling tools.

Cutter Model Diameter(mm) Total Height(mm) Height of Diamond Layer Chamfer of Diamond Layer
0808 8.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1008 10.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1308 13.44±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1313 13.44±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1608 16.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1613 16.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1616 16.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
1908 19.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1913 19.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1916 19.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2216 22.22±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2219 22.22±0.05 19.0±0.1 2.0±0.1 0.41±0.05



Advantages of PDC inserts: 10 times longer service life than carbide!

1, high hardness, high wear resistance, high impact resistance.
2. The service life is 5-10 times longer than ordinary cemented carbide, which significantly reduces the frequency of replacing drill bits.
3. Effective and stable drilling speed, protect equipment and reduce drilling cost (30%-40% of total cost)

19mm 1008 Polycrystalline Diamond Compacts Anti Impact Carbide Buttons 0



Our Principle

We adhere to the principles of high quality, excellent service and innovation. We also adhere to provide efficient products and quality services. If you are interested in our drills, please feel free to contact us. We look forward to working with you!



FAQ

Q1. Is your company a distributor or a manufacturer?
A: We are a a professional factory of rock drilling bits in China.



Q2. How about your products?
A: All our activities are accredited to ISO9001: 2008, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request. We have many high quality bits.



Q3. What is the Packaging&Delivery?
A: We use high quality export carton or standard export woodern case.



Q4. What is the time about the delivery?
A: Ready to deliver within 1 week, if in stock.
Depends on order quantity, when out of stock, 7-30 days
Transportation: sea or air
