Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button

Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button
Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button

Large Image :  Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO9001
Model Number: zhui1621
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: To be negotiable
Packaging Details: customized
Delivery Time: 5-7 work days
Payment Terms: L/C, T/T
Supply Ability: 1000pcs per day

Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button

Description
Application: Coal Mining,cutting Machine Type: Drilling Tool
Material: Hard Alloy Sample: Available
Cutter Model: 0808
High Light:

hard alloy polycrystalline diamond inserts

,

tungsten polycrystalline diamond inserts

,

PDC carbide mining button

Cone Cutter PDC Cutter Manufacturers Polycrystalline Diamond Compact



Cone PDC cutters are mainly used for oil drilling equipment and wearing parts of oil drill bits, coal drill bits and machining tools. They are made from high-quality synthetic diamond powder and tungsten carbide powder.

PDC tools combine the high hardness and wear resistance of diamond and tungsten carbide and can be used in a wide variety of drill tools.



Cutter Model Diameter(mm) Total Height(mm) Height of Diamond Layer Chamfer of Diamond Layer
0808 8.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1008 10.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1308 13.44±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1313 13.44±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1608 16.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1613 16.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1616 16.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
1908 19.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1913 19.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1916 19.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2216 22.22±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2219 22.22±0.05 19.0±0.1 2.0±0.1 0.41±0.05



Advantages of PDC inserts: 10 times longer life than cemented carbide!

1.High hardness, high wear resistance, high impact resistance.
2. The service life is 5-10 times longer than ordinary cemented carbide, which significantly reduces the frequency of replacing drill bits.
3. Effective and stable drilling speed, protect equipment and reduce drilling cost (accounting for 30%-40% of total cost)



Hard Alloy Tungsten Polycrystalline Diamond Inserts PDC Carbide Mining Button 0



Our Principle

We adhere to the principles of high quality, excellent service, and the courage to innovate. We also adhere to provide efficient products and quality services. Please feel free to contact us if you are interested in our drills. We are looking forward to cooperating with you!



FAQ

1. Who are we?
We are a drill bit manufacturer started from 2013. Our main prodcuts are pdc drill bit for oil&gas, coal mining drill bit, core bit, pdc cutters and other types of pdc bits.



2. How can we guarantee the product quality?
We provide pre-production sample before mass production.
We provide final inspection before shipment.



3. Whether accpect customized products according to client's requirement?
A: Yes, we accept customization, no matter how much the purchase quantity is.

4. What is your payment terms?
Our payment terms: T/T (normally 30% deposit ,balance 70% before shippment) or LC at sight.

Communication knows no boundaries, no matter how far we are. Please feel free to contact us if you have any questions.
