Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond

Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond
Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond

Large Image :  Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO9001
Model Number: liangleng1613
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: To be negotiable
Packaging Details: customized
Delivery Time: 5-7 work days
Payment Terms: L/C, T/T
Supply Ability: 1000pcs per day

Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond

Description
Machine Type: Drilling Tool Material: Carbide,Carbon Steel
Use: Well Drilling,Coal Mining,Oil Or Gas Drilling Product Name: PDC Cutter,PDC Drill Bit
Edge: 2 Cutter Model: 1313
High Light:

two edge PDC inserts

,

gas drilling PDC inserts

,

1313 PDC diamond

Two-edge PDC Cutter Polycrystalline Diamond Compact



PDC cutters are mainly used for oil drilling equipment and wearing parts of oil drill bits, coal drill bits and machining tools. They are made from high-quality synthetic diamond powder and tungsten carbide powder.

PDC tools combine the high hardness and wear resistance of diamond and tungsten carbide and can be used in a wide variety of drill tools.



Cutter Model Diameter(mm) Total Height(mm) Height of Diamond Layer Chamfer of Diamond Layer
0808 8.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1008 10.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1308 13.44±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1313 13.44±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1608 16.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1613 16.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1616 16.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
1908 19.0±0.05 8.0±0.1 2.0±0.1 0.41±0.05
1913 19.0±0.05 13.00±0.1 2.0±0.1 0.41±0.05
1916 19.0±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2216 22.22±0.05 16.0±0.1 2.0±0.1 0.41±0.05
2219 22.22±0.05 19.0±0.1 2.0±0.1 0.41±0.05



1. high hardness, high wear resistance, high impact resistance.
2. The service life is 5-10 times longer than ordinary cemented carbide, which significantly reduces the frequency of replacing drill bits.
3. Effective and stable drilling speed, protect equipment and reduce drilling cost (accounting for 30%-40% of total cost)



Two Edge PDC Inserts Gas Drilling 1313 PDC Diamond 0



Our Principle

We adhere to the principles of high quality, high quality service, and innovation. We also insist on providing efficient products and excellent service. Please feel free to contact us if you are interested in our drills. We look forward to working with you!



FAQ

1. Are you a trading company or manufacturer?

We have manufactured pdc cutters since 2013, so we have price advantages.



2. How can we guarantee the product quality?
We provide pre-production sample before mass production.
We provide final inspection before shipment.



3. About lead time and shipping time?

The lead time depends on the quantity of the order. Usually, it will take 3-5 days to ship to Tianjin Port or XI'AN Airport, China. For the small order or urgent order, we can send you by air once the order is confirmed.



4. Is it produced according to the standard? And can I expect a quality product?

Yes, all our activities are ISO9001 certified, both products and services. At the same time, mature production technology will ensure the quality meets international requirements. We have carried out strict inspection in production. Our drill bits are exported to Middle East, Europe, North America, South America, Australia and other countries and regions.





Communication knows no boundaries, no matter how far we are. Please feel free to contact us if you have any questions.
