Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling

Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling
Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling

Large Image :  Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO 9001
Model Number: 8-3/4 HS6532TB
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: To be negotiable
Packaging Details: iron case
Delivery Time: 5-7 business days
Payment Terms: T/T, L/C
Supply Ability: 20pcs per day

Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling

Description
Diameter: 8 3/4", 222.25mm Advantage: High Quality, Reasonable Price
Blades: 5 Blades Material: Polycrystalline Diamond Compact Cutters
Use: Coal Mining, Oilfield Well Drilling Color: As Required
High Light:

carbide oil well drill bit

,

tungsten oil well drill bit

,

8 nozzle PDC bit for well drilling

8.75inch 5 Blades Tungsten Carbide Drill Bits Diamond Drill Bit Oil Well



1. Rolling seal bearing structure, the cylindrical roller cone is in the groove, which increases the size of the

journal.

2. Thrust bearing pairs are surface-treated and hardened respectively.

3. Steel ball clamping for high speed.



PRODUCT SPECIFICATIONS
Size 8 3/4 inch (Φ222.25mm)
Model number 8-3/4 HS6532TB
Body type steel body
Number of blade 5
Primary PDC cutter size 1613
Number of nozzle 8
Gauge length 83.15mm
API connection 4-1/2 REG
Make-Up Torque(KN.m) 16.3~21.7(4.79) KN·m(Mpa)
Application Oil & Nature Gas
Quality High Level
Package Iron Case
MOQ 5 Pieces
Certificate ISO 9001
OEM Yes
Customized Size Yes



Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling 0

Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling 1

Package&Delivery

Our bits will be shipped within 4 days after 50% full payment is received by sea or air as you require.

Please contact us freely if you have any other requests.


Carbide Tungsten Oil Well Drill Bit 8 Nozzle PDC For Well Drilling 2


Our Principle

Our goal is to provide our customers with the best quality tools, accessories and service in the industry. We are supported by many years of experience, trained professionals and a full machine shop. Reduce the cost ,Speed the drilling ,Guarantee the safety is always our aim.



FAQ

1. Are you a trading company or manufacturer?

We have been a professional manufacturer of PDC bits since 2013.



2. Whether accept customized according to clients' requirements?

Yes, We accept customized products, no matter what size and what type. Please feel free to contact us.



3. About lead time and shipping time?

The lead time depends on the quantity of the order. Usually, it will take 3-5 days to ship to Tianjin Port or XI'AN Airport, China. For the small order or urgent order, we can send you by air once the order is confirmed.



4. Is it produced according to the standard? And can I expect a quality product?

Yes, all our activities are accredited to ISO9001: 2015, both in products and services. At the same time, mature production technology will ensure the quality to satisfy the international request. We have strictly inspection in the production. Our bits are exported to the Middle East, Europe, North America, South America, Australia, and other countries and regions.



5. How do you guarantee your quality?

We select the advanced production technology and equipment, strictly control the whole production process, and inspect the finished drill bits. We can also make several design changes according to the customer's feedback, and finally ensure the customer's excellent drilling effect.
