Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling

Certification
China Shaanxi Hainaisen Petroleum Technology Co.,Ltd certification
China Shaanxi Hainaisen Petroleum Technology Co.,Ltd certification
I'm Online Chat Now

Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling

Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling
Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling

Large Image :  Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO 9001
Model Number: 8-1/2 HS96320C
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: To be negotiable
Packaging Details: iron case
Delivery Time: 5-7 business days
Payment Terms: T/T, L/C
Supply Ability: 20pcs per day

Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling

Description
Diameter: 8 1/2in Or 215.9mm Cutter Size: 19mm
Blades: 3 - 9 Blades Name: Pdc For Drilling Bits
Application: Oilfield
High Light:

oilfield Steel Body PDC Bit

,

19mm Steel Body PDC Bit

,

9 blade PDC bit for well drilling

8-1/2inch 6 Blades Drilling Tiles Drill Bit Oilfield Drill Bit PDC Cutters Bit



1. Cutting structure is force balanced and bit blade is asymmetrically designed so that the load on bit is balanced

    that resulting better stability of the bit.
2. Main cutter are high performance PDC cutters to insure service life of the bit while improving ROP.
3. Cutter exposure is optimized to insure the oil bit can achieve higher ROP is soft to medium formations.
4. Shock absorbers are designed to make the bit capable of drilling through formations with hard stringers.
5. Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to enhance cleaning

   and cooling effects of the bit to effectively prevent bit from balling.



PRODUCT SPECIFICATIONS
Size 8 1/2 inch (Φ215.9mm)
Model number 8-1/2 HS96320C
Body type steel body
Number of blade 6
Primary PDC cutter size 1913
Number of nozzle 7
Gauge length 79.27mm
API connection 4-1/2 REG
Make-Up Torque(KN.m) 16.3~21.7(4.79) KN·m(Mpa)
Application Oil & Nature Gas
Quality High Level
Package Iron Case
MOQ 5 Pieces
Certificate ISO 9001
OEM Yes
Customized Size Yes



Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling 0

Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling 1


Package&Delivery

Our bits will be shipped within 5 days after 40% full payment is received. They will be shipped by sea or air according to your requirements. Please feel free to contact us if you have any other requests. Thanks!



Oilfield 19mm Steel Body PDC Bit , 9 Blade PDC Bit For Well Drilling 2



Our Principle

Our goal is to provide our customers with the best quality products and services. We have a professional R&D team, domestic advanced production equipment and precision instruments to reduce costs, speed up drilling and ensure safety.
Win-win cooperation is our ultimate pursuit. If you are looking for drill bit manufacturers, please feel free to contact us.



FAQ

1. Is your company a distributor or a manufacturer?
A: We are a professional pdc drill bit manufacturer in China since the year 2013.



2. Can I expect a good-quality product?

Of course. All our activities are accredited to ISO9001, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.

Our bits are exported to the Middle East, Europe, North America, South America, Australia, and other countries and regions.



3. How to order the products?

Send an inquiry of the details of the item or Model number you want. If there is no packing demand, we will take it as sea-way packing. Please attach a reference picture or any links from our website to avoid any misunderstanding. Thanks so much!



4. What's your MOQ?
Our MOQ is 1 piece, but if you just want sample test quality we can surely supply to you.



Communication knows no boundaries, no matter where you are.

If you have any requests, please feel free to contact us at anytime!
