Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button

Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button
Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button

Large Image :  Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button

Product Details:
Place of Origin: China
Brand Name: Hainaisen
Certification: ISO9001
Model Number: 8-1/2 HS65220B
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: To be negotiable
Packaging Details: iron case
Delivery Time: 5-7 business days
Payment Terms: T/T, L/C
Supply Ability: 20pcs per day

Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button

Description
Size: 8 1/2 In Or 215.9mm Use: Well Drilling,Coal Mining
Color: Request Name: PDC Drill Bits
Number Of Nozzle: 7
High Light:

oil Steel Body PDC Bit

,

7 nozzle Steel Body PDC Bit

,

5 blades dth hammer button bits

8-1/2in 5 Blade Oil Drill Bit Drilling Machine Diamond Rock Bits

1. The force of the cutting structure is balanced, and the asymmetrical design of the drill blade makes the force of the drill bit balanced and the stability of the drill bit better.
2. The main cutter adopts high-performance PDC cutter, which can ensure the service life of the drill bit and improve the ROP.
3. Optimize tool exposure to ensure that oil drills can achieve higher ROP, from soft to moderate formations.
4. The shock absorber is designed to allow the drill bit to drill through formations with stiff stringers.
5. Using dynamic flow pattern simulation technology to optimize the hydraulic system of the drill bit, enhance the cleaning and cooling effect of the drill bit, and effectively prevent the bit from pilling.



PRODUCT SPECIFICATIONS
Size 8 1/2 inch (Φ215.9mm)
Model number 8-1/2 HS65220B
Body type steel body
Number of blade 5
Primary PDC cutter size 1613
Number of nozzle 7
Gauge length 56.2mm
API connection 4-1/2 REG
Make-Up Torque(KN.m) 16.3~21.7(4.79) KN·m(Mpa)
Application Oil & Nature Gas
Quality High Level
Package Iron Case
MOQ 5 Pieces
Certificate ISO 9001
OEM Yes
Customized Size Yes


Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button 0
Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button 1
Package&Delivery
Our drills will ship within 5 days after 50% full payment is confirmed. Drills will be shipped by sea or air according to your requirements. Please feel free to contact us if you have any other questions. Thanks!



Oil Steel Body PDC Bit 7 Nozzle 5 Blades Dth Hammer Button 2


Our Principle
We insist on the principles of high quality, high quality service and innovation. We also insist on providing efficient products and excellent service. If you are interested in our drills, please feel free to contact us. We are looking forward to cooperating with you!
